Product Description

CrownMicro Xavier X-1.5KW-PF1 PV-2500 12V Solar Inverter Price In Bangladesh.

CrownMicro Xavier X-1.5KW-PF1 PV-2500 12V Solar Inverter

Technical Specifications

Category	Specification
Model Name	X-1.5KW-PF1 (PV-2500)
Rated Power	1500VA / 1500W
INPUT
Voltage	230VAC
Selectable Voltage Range	170–280VAC (for PCs) / 90–280VAC (for home appliances)
Frequency Range	50Hz / 60Hz (auto sensing)
OUTPUT
AC Voltage Regulation (Battery Mode)	230VAC ±5%
Output Power	1500W with PV & battery / 1200W with battery only
Surge Power	2400VA
Efficiency (Peak)	93%
Transfer Time	10ms (for personal computers)
Waveform	Pure sine wave
BATTERY
Battery Voltage	12VDC
Floating Charge Voltage	13.5VDC
Overcharge Protection	16VDC
Battery Type	Lithium / Lead-acid
SOLAR CHARGER & AC CHARGER
Solar Charger Type	MPPT
Max PV Array Open-Circuit Voltage	400VDC
Max PV Array Power	2500W
MPPT Range @ Operating Voltage	30–400VDC (30–60V with battery)
Max Solar Charge Current	80A
Max AC Charge Current	80A
Max Charge Current	80A
GENERAL SPECIFICATIONS
Dimensions (D×W×H)	90 × 283 × 357 mm
Net Weight	6.6 kg
Communication Interface	RS232
OPERATING ENVIRONMENT
Humidity	5%–95% RH (non-condensing)
Operating Temperature	−10°C to +50°C
Storage Temperature	−15°C to +60°C
